Numerical Analysis and Optimization of Spring-Damper Model for Evaluating Soil-Structure Interaction in Semi-Buried Heavy Structures Under Seismic Loads

Pirmohammadi Alishah, Farhad; Emami, Kamal

doi:10.22034/cpj.2025.524306.1368

Numerical Analysis and Optimization of Spring-Damper Model for Evaluating Soil-Structure Interaction in Semi-Buried Heavy Structures Under Seismic Loads

https://doi.org/10.22034/cpj.2025.524306.1368

Volume 7, Issue 4 - Serial Number 74
July 2025

Pages 72-99

Document Type : Research Article

Authors

farhad pirmohammadi alishah ¹

Kamal Emami ²

¹ Faculty Member and Assistant Professor, Department of Civil Engineering, Faculty of Engineering and Engineering, Islamic Azad University, Shabestar Branch, Shabestar, Iran

² Department of Civil Engineering, Faculty of Engineering, Islamic Azad University, Shabestar Branch, Shabestar, Iran

Abstract

Soil-structure interaction (SSI) plays a crucial role in realistically predicting the behavior of structures compared to rigid base assumptions. In this study, the seismic response of semi-buried heavy structures was investigated using a mass–spring–damper model to capture SSI effects. Eleven soil samples with diverse behavioral characteristics were considered to compare the responses of structures with rigid supports and those with flexible, soil-supported bases. Numerical models were developed and analyzed using SAP2000 software. To ensure the reliability of the results, a benchmark SSI study from the literature was selected for validation, demonstrating an acceptable level of accuracy and convergence. Key soil properties for common construction soils were incorporated. Following careful selection and scaling of appropriate earthquake records according to Iranian seismic code (Standard No. 2800), nonlinear dynamic analyses were conducted. The findings clearly illustrate the significance of SSI, particularly for silty soils, where the interaction effect is pronounced. Incorporating SSI led to a considerable increase in base shear values, underscoring the necessity of accounting for these effects in the seismic design of heavy, semi-buried structures.

Keywords

Soil-structure interaction

Seismic analysis

Semi-buried structures

Spring-damper model

Nonlinear dynamic analysis

Subjects

civil engineering

Alavi, E., & Gandomzadeh, A. (2020). Nonlinear Soil-Structure Interaction Modeling for Heavy
Embedded Structures. Engineering Structures, 216, 110780.
ASCE 7-22 (2022). Minimum Design Loads and Associated Criteria for Buildings and Other
Structures. American Society of Civil Engineers.
Building and Housing Research Center (BHRC). (2019). “Iranian Code of Practice for Seismic
Resistant Design of Buildings (Standard No. 2800),” 4th Edition, Tehran, Iran.
Computers and Structures, Inc. (2023). SAP2000 v24 Integrated Finite Element Analysis and
Design of Structures – User Manual. California, USA.
Chen, Q., Li, S., Shi, Y. (2023). Numerical Study of SSI Effects on Base Shear of Structures in Silty
Soils. Soil Dynamics and Earthquake Engineering, 167, 107469.
Chen, X., & Shi, Y. (2013). Soil–Structure Interaction Analysis of Seismic Response in Underground
Structures. Earthquake Engineering and Engineering Vibration, 12(1), 1–8.
Jin, X., Zhang, Y., & He, F. (2022). Selection and Scaling of Earthquake Ground Motion Records
for SSI Analysis. Earthquake Engineering & Structural Dynamics, 51(7), 1682–1699.
Jung, S.K. (2009). Influence of Soil-Structure Interaction on the Seismic Response of Building
Structures. Journal of Structural Engineering, 135(4), 482-492.
Hong, Z., et al. (2007). Three-dimensional finite element analysis of soil–structure interaction for
underground structures. Tunnelling and Underground Space Technology, 22(4), 433–441.
Kaynia, A.M., & Kausel, E. (2020). Advances in Soil–Structure Interaction Analysis: Theory and
Applications. Soil Dynamics and Earthquake Engineering, 133, 106128.
Khosravikia, F., Alavi, E., Gandomzadeh, A. (2019). Use of Equivalent Spring-Damper Models to
Simulate Subsurface SSI Effects. International Journal of Civil Engineering, 17(6), 771–786.
Mylonakis, G., & Gazetas, G. (2000). Seismic Soil–Structure Interaction: New Evidence and
Emerging Issues. Geotechnique, 50(3), 333–355.
Patra, S.K., Mukherjee, S., Dey, S., & Gupta, S. (2023). Influence of Soil–Structure Interaction on
Seismic Assessment of Subsurface Structures. Bulletin of Earthquake Engineering, 21, 1919–1946.
Stewart, J.P., Seed, R.B., & Idriss, I.M. (1999). Earthquake Ground Motion Scaling Procedures for
Geotechnical Applications. Earthquake Spectra, 15(2), 171–205.
Vafaei, B., Ghassemi, M.R., & Habibnejad Korayem, A. (2021). Evaluation of Glacial and Alluvial
Soil Deposits in Northwestern Iran. Journal of Earth System Science, 130, 215.
Zhang, M., Wang, X., & Wei, X. (2022). Effects of Soil–Structure Interaction on Seismic
Performance of Underground Structures. Engineering Structures, 266, 114536.
